Balboa Spa Control BP7 Series [5.5kW] [240v]Control Box & topside [51-G6506]

Balboa Retro-fit, BP7 Series, 5.5kW, Control Box & topside [51-G6506]

System is Required to be installed by Professional Spa Technician

(and any replacement board) is typically shipped in Setup 21

Topside Dimensions

7 3/8 " wide x 3 1/4" tall

• Power Point Download

• Installation PDF

• The BP family of Hot Tub Control Systems were designed using Balboa's patented M7™ temperature and flow sensor technology and a new universal control platform.
• The systems have a plastic enclosure to eliminate water intrusion.
• Connectors are built onto the circuit board minimizing wires and simplifying service.
• The different models have controls for a single two-speed pump or an additional blower or pump.
• All models feature a convertible 115/230v power supply, a 1.4/4.0kW heater and can support mini, duplex, or standard digital control panels.

Height	Width	Depth
10-9/16"	12-1/4"	4-1/2"

Number Of Appliances	Pump1 + Pump2 + Pump3 + Pump4 + Blower
Manufacturer	Balboa Water Group
Model	BP7
Supply Voltage	120/230v - 3 Wire, 230v - 4 Wire
Heater Type	Fixed - Bottom
Heater Wattage	5.5kW
Topside Included	TP600
Circ Pump Ready	Optional 115v/230v
Auxiliary Topside Ready	Yes
Fiber Optic	No
Accessory Ready	Yes
Wi-Fi Compatible	Yes
50/60 HZ	50Hz, 60Hz
