Balboa VS510SZ Spa Control System [NO Cords] (54371HC2)
System is Required to be installed by Professional Spa Technician (and any replacement board) is typically shipped in Setup 21
NOTE: The 25657 Topside Splitter Cable no longer comes with the BP7 packs. If using a topside and a wifi module, you will need to plug 1 into J34 and the other into J35.
Balboa Water Group BP7 Control System
Kit includes: system, panel, panel adapter plate, light cord and overlay(s)
| Topside Dimensions |
| 6-3/8 " wide x 2-1/4" tall |
-
Power Configuration: 60Hz / 40A / 240v
System Outputs:
-
240 VAC Pump #1
-
240 VAC Pump #2
-
240 VAC Blower
-
120/240v circulation pump
-
4.0 kW Heater
-
115/240 VAC Ozone (must match circ pump)
-
12 VAC Spa Light
