ThermaSol Digital Shower Valve (TDS-3000) Steam Shower, Digital Valve, 3 Output
The TDS-3000 is no longer available and not in stock. We are a few months out from having the next version available for purchase.
Steam Shower, Digital Valve, 3 Output
The Smart Digital Shower Valve allows precision control of water volume and exact temperatures. With a minimalist look desired by top architects, ThermaSol’s Digital Shower eliminates the need for exposed valves and trims. Designed to be concealed in walls the Digital Valve is technology you enjoy, but don't see.
Digital Shower Valve only
FEATURES:
- Precise temperature control
- Precise water volume control
- Eliminates exposed valves and trims
- Ceramic disc Fluhs
- 2 industrial grade stepper motors
- Solenoid valve systems
- Integrated diverter
- Three output valve
- IAPMO approved
- Designed, engineered, and crafted in the U.S.A
- Dimensions: 11"W x 3"D x 7"H
- 5 year warranty
INCLUDES:
- Digital Shower Valve
- Screw set
- Connection nipple set
- CAN-bus cable 50ft'
- Digital interface
- Back up battery
- Installation manual
- Warranty
INSTALLATION MANUAL
| Model |
Digital Shower Valve |
| 2 Inputs |
1/2" FNPT |
| 3 Outputs |
1/2" FNPT |
| Power Supply |
|
| Input |
11VAC, 0.5 Amps |
| Output |
15VDC, 3 Amps required |
| Shipping Weight |
10.65 lbs |
| Width |
11" |
| Depth |
3" |
| Height |
7" |
